✨ JSD1832A2 24-Bit A/D Digital Dynamic Signal Analyzer
Voltage / IEPE Input | Data Collector | High-Precision Electronic Data System
The JSD1832A2 is a high-resolution, 24-bit dynamic signal analyzer designed for accurate multi-channel data acquisition. Supporting both Voltage and IEPE inputs, it ensures precise and reliable signal capture across a wide range of industrial and research applications. With robust construction and versatile interface options, it’s built for performance in even the most demanding environments.
🔧 Features at a Glance:
24-bit high-accuracy A/D conversion
Supports both Voltage and IEPE sensor inputs
Stable and synchronized multi-channel acquisition
USB, Ethernet, and RS485 connectivity
Ideal for vibration, acoustic, and structural testing
Unlock smarter signal analysis with the JSD1832A2 — where precision meets reliability.
Number of input channels |
32 |
AD resolution |
24 bits |
Sampling method |
parallel synchronous sampling |
Data transmission interface |
USB2.0 |
Signal-to-noise ratio |
≥100 dB |
Linearity |
0.1% of full scale |
Input method |
Voltage/IEPE |
D/A conversion rate |
500KHz |
Signal output range |
±10VPEAK |
Signal output bandwidth |
DC - 100kHz (-3dB) |
Overall dimensions |
W269mm×H68mm×D228mm |
Power supply |
100 – 240V AC, 50/60Hz |
Working temperature |
0~ 40℃ |
Weight |
2.5Kg |
A: Yes, We are professional sensor manufacturer over 50 years! Our technical team has more than 20 engineers.
Q: Can you accept OEM service ?
A: Yes, we can put your company information and logo on our sensors.
Q: Can I be your distributor?
A: Yes, we are looking for distributors in oversea market.
Q: What is your lead time?
A: Normally 7-10days. For quantity above100pcs, need extra 3-5 working days.
